SURFACE COMMAND / CONTROL

Complete Camera Authority from Topside. Robust, Reliable, 100% Gates.

Myriad underwater applications require surface control of underwater rigs, and the solution is Gates Surface Command / Control suite of cables and interconnects.

Four distinct categories of system control are available: Power (DC 15 or 24V), Camera (ethernet), Lens (serial), and Video Feed (SDI). Each category utilizes a tough, dedicated tether cable for the task, one that meets Gates’ stringent requirements for resiliency, flexibility, and reliability. When warranted, cables can be water / air blocked as well.

Integrated on most tethers is Gates MultiConn (GMC), a robust sealed bulkhead connector of Gates original and proprietary design. Genuine LEMO connector inserts are integral to GMC for reliable signal integrity, including ethernet and serial interfaces.

When difficult protocols are encountered (e.g. HDMI), Gates ‘pass through’ bulkhead cable penetrator (BCP) design provides the absolute highest signal reliability. In such cases, BCP’s are made with custom-manufactured marine-grade cables meeting Gates specifications including air / water block compounds, keeping your valuable camera gear safe and dry.

Surface Command / Control system is Gates through-and-through. Underwater Pros know that failure is not an option. They never take a chance…. they take a Gates!

Compatible Housings: DEEP WEAPON – RAPTOR ARRI MINI LF ALEXA 35
See Selection Tab for full list, or Contact Gates

Key Features

Surface Authority

All functional categories are covered:
- Camera control
- Lens control (LCS)
- Video feed
- Power.

Gates MultiConn (GMC) Bulkhead Connectors

Real innovation. Gates proprietary MultiConn is another 'bulletproof' design, a sealed bulkhead connector. Primarily for Surface Tethers, it can also be used on Gates External Monitors and custom interconnects.

Versatile, Adaptable

Surface Command / Control integrates with all Gates underwater housings including DEEP WEAPON – RAPTOR, ARRI MINI LF, ALEXA 35, and Custom Housings as well.

Robust, Reliable

Marine-grade cables, stainless steel / aluminum materials, and Gates 50+ years of experience lead to durable, dependable surface control.

LEMO Connectors

As generic connectors are a common failure point, Gates uses only genuine LEMO connectors whenever possible for consistent, reliable mating and robust signal integrity.

Gates Expertise

Gates capabilities, know-how and manufacturing are highly specialized, the result of 50+ years experience. A product with Gates name means you own the most reliable underwater equipment in the world.

Don't Take a Chance.... Take a Gates!

Construction, Connectors

316 Stainless steel.
6061-T6 Aluminum, Type III Hard Anodized finish.
C36000 Brass

Construction, Cables

Marine-grade.
Flexible polyurethane or PVC jacket.
Cross sectional rigidity.
Stranded core conductors.

Weight in Air

Variable depending cable / configuration.

Weight in Water

Variable depending cable / configuration

Depth Rating

Fully rated to max length of cable.

Surface Tethers

Remote Cinema Housing is 100% surface command / control, in four categories: Power, Video Feed, Lens Control, and Camera Control.

Power

Surface power source is typically power bank 24-28 VDC, delivered over Gates MultiConn and 14AWG / 2.5mm2 gauge wire for minimal losses.

SDI Video

Robust 3GHz swept coax cable and Gates MultConn 75Ω Triax delivers 3G-SDI video up to 150 feet.

Lens Control

Gates MultiConn is ideal for supporting various LCS brands including ARRI, Cmotion, Preston, and Teradek RT.

Camera Control

Ethernet is the de facto standard protocol of nearly all supported cameras, allowing for straightforward surface interface with Gates MultiConn and tough, polyurethane jacketed CAT5 cable.
